CART, C4.5, ID3 Algorithms

CART:

CART (Classification and Regression Trees).
CART is a versatile algorithm that can be used for both classification and regression tasks.
It constructs binary decision trees, where each internal node represents a splitting criterion on a feature, and each leaf node represents a class label or a regression value.
The splitting criterion in CART is determined by optimizing a cost function, such as the Gini index for classification or the mean squared error for regression.
The algorithm recursively partitions the data based on the selected feature and splits, creating branches until a stopping condition is met.
For classification, the majority class label in a leaf node is assigned to instances falling into that region, while for regression, the average value of instances in a leaf node is assigned.
CART allows for pruning, where unnecessary branches are removed to reduce overfitting and improve generalization.

ID3 (Iterative Dichotomiser 3).
ID3 is a decision tree algorithm primarily used for classification tasks.
It constructs multi-way (non-binary) decision trees, where each internal node represents a splitting criterion on a feature, and each leaf node represents a class label.
The splitting criterion in ID3 is based on the concept of information gain, which measures the reduction in entropy (or alternatively, the Gini index) achieved by a split.
The algorithm follows a top-down, greedy approach, where it selects the feature with the highest information gain at each node to create splits.
ID3 continues recursively until either all instances in a node belong to the same class, or there are no more features to split on.
ID3 does not handle missing values well and can create overfit trees that are sensitive to noisy or irrelevant features.

C4.5 algorithm is improved over the ID3 algorithm, where “C” shows the algorithm is written in C and the 4.5 specific version of the algorithm.
splitting criterion used by C4.5 is the normalized information gain (difference in entropy).
The attribute with the highest normalized information gain is chosen to make the decision.
The C4.5 algorithm then recurses on the partitioned sub lists.
